Slim UV-365 LED Penlight (365 nm)

powerful enough to cure windshield repair UV-cure adhesives in minutes

Part Number: SNLSMUV365

Online $129.00
Retail $129.00

UV-365 new website Forum on UV LEDs


In Stock Typically ships in 1-2 business days Contact US at (785) 832-8818 or jeff@sunlitest.com about Bulk Rate for 5 + Units Warning: Wear UV safety glasses when working with this UV light

Features

Push button on-off switch with momentary and constant illumination features.
Copper substrate and reflector to quickly drain the generated heat to the flashlight housing.
Anodized aluminum alloy housing, also functions as heat sink.
Recessed glass lens to prevent scratch and yellowing

Optional Features

Optional white or Color Slim LED heads
Optional 12 inch and 4 inch flexible tube
Optional headset attachment
The UV LED head can be attached to CR123 or rechargeable power unit

Slim UV-365 LED Penlight

Accessories and Parts:

H eadset Attachment and Flexible tube
S lim LED Head s
Slim Housing and Rubber sleeve
Contacting PCB , Pocket Clip

Specifications
Power	initial: input 2 W, output 125 mW
Wavelength	365-370 nm
Current	Initial: ~550 mA
Size	6.1 in. X 0.51 in.
Weight	2.1 o.z. (with batteries)
Power source	3 AAA batteries
Run time	~ 8 hours
Color	Silver
Others	Water resistant and shock resistant

LED Undercabinet Light
(410-550 lumens)
LED C eiling Light
(1620-4600 lumens)
LED Underhood Light
(1620 lumens)
LED Workstation Light
(rechargeable, 350 lumens)
LED Car Light
(350 lumens)
LED Utility Light
(rechargeable, 350 lumens)

LED UV Light
UV-365 light
(for non destrustive testing & curing)
UV-395 Light
(leak detecting; fossil,scorpion detecting)

LED Penlight
Slim3W (100 lumen )
Slim1W (65 lumen )
Slim2 (6 0 lumen)
Slim Jr . (30 lumen)

LED Rechargeable Flashlight
Turbo Model LED Flashlight
(Dual Switches, rechargeable)
16WFP (580 lumens)
80 FP (550 lumens)
12WFP (580 lumens)
8WFP (320 lumens)
Turbo (220 lumens)

Eagle Model LED Flashlight
(magnetic endcap, rechargeable)

LED CR123 Light
CR123 Flashlight
(250 lumens, strobing feature)
T urbo J r Pistol Light
(180 lumen)

LED Tool Light, AAA version
Eagle TriA (120 lumen)

LEDs
LED head, flood light
LED head, concentrated center beam
Turbo LED
Eagle L ED
S lim LED
Slim Jr. LED

Accessories
Headset Attachment, Flexible Tubes, Fixture
For all Rechargeable Lights
Batteries and Chargers
Belt Pouch
Lanyard
For Turbo Model RCHG, CR123 Lights
Tailc ap,Pressue switch
Gun Mount, Pressure Button
Rubber Sleeve
For Eagle Model RCHG
Magnetic Endcap
For Slim Penlights
Rubber Sleeve
Contacting PCB
For Slim Jr. Penlights
Flexible tube
Contacting PCB

Parts
Housings, Endcap, Side Switch
Turbo Model
Eagle Model
CR123 version
TriA
Slim
Slim Jr.
Other Small Parts
Utility Light (Side Magnet, Hook)
1 6WFP (Lens, Lens ring, Reflector)
8WFP(Lens, Lens ring)
Eagle(Lens, Lens ring)

Products

Our UV-365 LED lights will not degrade since we use glass lens.

Other UV lights that are built with multiple T-13/4 epoxy-encapsulated UV LED lamps will degrade 50% after 500
hours because the epoxy encapsulation turns yellow after exposed to the UV light.

Our UV-365 LED lights will not have significant wavelength shift even at high current of 1200mA because
the LED chip is direclty alloyed onto the copper base and the heat generated from the chip is efficiently
drained.

Other epoxy-encapsulated UV LED light will shift to a much longer wavelength (the high the current, the longer the
wavelength) after being on for a few seconds because heat generated from the LED chip becomes trapped, and the
temperature of the LED chip will rise to over 125 degree C in only a few seconds.
